19 Inch 4U 9U Wall Mount Server Rack Cabinet Communication Network Enclosure

Basic Information
Place of Origin: Zhejiang,China
Brand Name: LE
Certification: ISO 9001:2008,CE,ROHS,SGS,TUV,BV
Model Number: LE-WS1
Minimum Order Quantity: 1
Packaging Details: Flat packing:plastic bag+protected corner+carton
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union, D/A, D/P
Supply Ability: 5000pcs per day
Materila: SPCC Quality Cold Rolled Steel Color:: Ral9004;Ral9005;Ral7035
Material Thickness: 1.2mm;tempered Glass:5.0mm Loading Capacity: 100kg
Degree Of Protection: IP20 Width: 600mm
Depth: 450mm,600mm Height: 4-22U
High Light:

small wall mount server rack

,

floor mount network rack

,

SPCC 9u wall mount server rack

19inch 4U 9U wall mount server rack communication network enclourse



General Description:

1. Welded frame, single section, compatible with 19" standard equipments;

2. 5mm tempered glass front door with over 180 turning degree;

3. Removable side panel, easy to install and lock optional;

4. Cable entry on the top and bottom;

5. L-shaped mounting profile, easy to adjustable on the mounting rail;

6. Fan cutout on the top, easy to install fan;

7. Installing back panel, easy to fix on the wall;

8. Various accessories for option;



S/N LE-WS1
Material SPCC quality cold rolled steel
Loading Capacity 60kg
Degree of Protection IP20
Surface Finish Degreasing,Pickling,Phosphating,Powder Coated
Production Specification 4-22U
Width 600mm
Depth 450mm,600mm
Color Ral9004;Ral9005;Ral7035



Order Codes Capacity W*D*H(mm)
LE-WS1-6404 4 600*450*279
LE-WS1-6604 4 600*600*279
LE-WS1-6412 12 600*450*634
LE-WS1-6612 12 600*600*634
LE-WS1-6422 22 600*450*1081
LE-WS1-6622 22 600*600*1081



Packing

Plastic bag+protected corner+carton

19 Inch 4U 9U Wall Mount Server Rack Cabinet Communication Network Enclosure 0

19 Inch 4U 9U Wall Mount Server Rack Cabinet Communication Network Enclosure 1



FAQ

Q1: Are you manufacturer of trading company?
A1: We are a manufacturer in Zhejiang, China.

Q2: When can we get the reply?
A2: Any inquiries will be replied within 24 hours, but holidays are excepted.

Q3: Can I get some samples?
A3: Yes, sample order is available for quality check and market test.

Q4: What is your payment term?
A4: We usually accepet T/T as the main payment term, and other payments can also be negotiated.

Q5: What is the delivery time?
A5: It usually takes about 15-30 days to prouduce the products

Q6: Quality problems?
A6: If there is any quality problem or question, we could offer technical support or return service
