110 288vac 1kva 10kva Uninterrupted Power Supply Ups

Basic Information
Place of Origin: China
Brand Name: LE or OEM
Certification: CE/UL/ROHS
Model Number: LE-HR11
Minimum Order Quantity: 6
Price: 198.67-1150 dollar
Packaging Details: disassembled packing
Delivery Time: within 4 weeks
Payment Terms: L/C, D/A, Western Union,paypal
Supply Ability: 10000 piece / pieces per week
Product Name: UPS Battery 110~288VAC 1kVA 10kVA Uninterrupted Power Supply (UPS) Capacity: 1-10kVA
Battery Type: Lead Acid Battery Wave Form: Pure Sine Wave Online UPS
Certification: ISO9001/ISO14001/CE Warranty: 1 Year
Display: LCD+LED Color: Black
Transfer Time: 0ms Gross Weight: 5kg
High Light:

110v uninterrupted power supply ups

,

1kva uninterrupted power supply ups

,

10kva uninterrupted power supply ups

UPS Battery 110~288VAC 1kVA 10kVA Uninterrupted Power Supply (UPS)



LE-HR11 Series Rack Online UPS 1-10kVA (220V/230V/240V)
LE-HR11 series, ranging from 1kVA to 10kVA, is double conversion online rack UPS with fully DSP controlled technology. The single
phase of 6-10kVA UPS applies the advanced 3-level technology, achieving a efficiency up to 95%. With its compact design of high
power density (kW=kVA) in 2U height, HR11 series make it ideal choice for computers, telecommunication equipment and other
sensitive devices.



Input voltage range 110Vac-288Vac
Input frequency 40-70Hz
Voltage regulation ±1 %
Output frequency 50/60Hz
Output PF 0.9/ 1.0
Overload capability
(Inverter mode)
105%-130%: to bypass 1 min; 150%: to bypass after 30 sec;
110%:for 10 min ;125%:for 1min ; 150%:for 30 sec
Overload capability
(Battery mode)
105%-130%: shutdown after 10 sec; 150%: shutdown after 5 sec;
110%: shut down after 1 min; 130%:shut down after 10 sec; >130%: shut down after 200 ms
Crest factor 3:1
Display LED+LCD
Interface RS232,EPO
Optional USB, SNMP, ECO kit, Dry contacts,
Battery cabinet
Operation temperature 0-40ºC
Application

IDC(Internet Data Center),network,servers and workstations, control system, communication system, office.



110 288vac 1kva 10kva Uninterrupted Power Supply Ups 0
Common features for 1-10kVA
Wide range of input voltage while input PF>99%
19" standard cabinet and battery cabinet
Full protection of overvoltage, circuit short and
over temperature
LCD/LED display, monitoring all the operation status
Automatic fan speed adjustment
Abundant interface: RS232,USB, SNMP, Intelligent Card

Unique features for 6-10kVA
High efficiency, up to 95%
kVA=kW, output PF=1
Intelligent charging management, effectively improving
the life time of battery
3 level of technology, compatible with complicated load

Related Products:
https://nbleit.en.made-in-china.com/product-list-1.html
110 288vac 1kva 10kva Uninterrupted Power Supply Ups 1

Ningbo Latitude Communication Equipment Co., Ltd is a professional manufacturer specialized in server cabinet, network cabinet, outdoor cabinet, wall cabinet and other communication equipment. For over 25 years, we are always devoting ourselves to research, develop, design and manufacture the indoor and outdoor cabinet products. striving to be effectively dynamic and innovative and always maintained a steady growth although the extremely competitive market, we have the advanced equipment including TruLaser incision machine, TruPunch Presses machine, CNC equipment, spraying paining line and other equipment. In order to assure the stable and high quality of products, we develop the quality control system and operate the manufacturing procession under the International quality system certification.If you are the distributor or agent of network cabling products, kindly contact us,we can provide one-stop service.Looking forward to having a pleasant business relationship with you in the near future.
110 288vac 1kva 10kva Uninterrupted Power Supply Ups 2
110 288vac 1kva 10kva Uninterrupted Power Supply Ups 3110 288vac 1kva 10kva Uninterrupted Power Supply Ups 4
- Q1: Are you a factory or trading company?
LE: We are a Factory, Distributor and Trading Company.

- Q2: Can I get a sample from you?
LE: Of course.You are welcome to place sample order to test our superior quality and service.

- Q3: What is the leading time?
LE: Sample order is 1-2 weeks, bulk order is about 25 days after receive the payment.

- Q4: Can you provide OEM products with my brand and logo?
LE: No problem. Just send us your brand Letter of Authorization.

- Q5: Where is your factory located? How can I visit there?
LE: Our factory and office is located in Ningbo City, China.You can fly to Ningbo airport or Shanghai airport.
If needed, we'd like to help you to book hotel and pick you up from the airport or train station.
Warmly welcome to visit us!


- Q6: How does your factory do regarding quality control?
LE: Quality is priority.We always attach great importance to quality controlling for to the very end.
Our factory has gained CE,ROHS,SGS authentication.
