Gigabit Ethernet Industrial SFP POE Media Converter

Basic Information
Place of Origin: China
Brand Name: LE or OEM
Certification: ISO
Model Number: LE-FEC10
Minimum Order Quantity: 1pcs
Price: 3-10 USD
Packaging Details: disassembled packing
Delivery Time: within 4 weeks
Supply Ability: 10000 piece / pieces per week
Place Of Origin: Ningbo Model Number: LE-FEC10
Fiber Type: SFP Operating Temperature: 40 ° ~85 ° C
Mounted Type: DIN-rail Color: Black
Certification: ISO9001
High Light:

SFP POE Media Converter

,

Gigabit POE Media Converter

,

Ethernet POE Media Converter


Product Description

Gigabit Ethernet fiber optic to rj45 SFP to copper industrial POE media converter from China

LE-FEC10 series is the 10/100/1000 Mbps industrial POE fiber media converter, comply with IEEE802.3af, power on POE IP cameras through the Ethernet cable, simple construction, power range up to 100 meters, operating temperature-40 ℃ to + 85 ℃, meet IP30 protection degree and EMC industrial grade requirements, DIN rail installation, pass through dangerous environmental certification and comply with FCC and CE standards. The reliable industrial grade design could ensure continuous and stable operation of the automation system.


Specification



Product Name
10/100/1000Mbps Industrial POE Fiber Media Converter (1F+1TP)
Model No.
LE-FEC10
Port
1 x 1000Mpbs port
MM:1310nm, 2Km
SM:1310nm/1550nm,20Km
1490nm/1550nm,40~120Km
1 x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Switching features
System bandwidth:40Gbps (non-traffic jam)
Transmission mode:storage and forward
Network media
SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km
100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m)
10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)






LEDs
Power, network, fiber
Power supply
(802.3at standards required special instructions)
Single PoE power supply output power: 15.4W
POE power supply input voltage: 48V (max 53V),
Reverse polarity protection: support
No-load power consumption: 5W
Input voltage: DC 12-36V
Environment
Storage humidity:10%~95%,non-condensing
Working humidity:10%~90%,non-condensing
Storage temperature:-40°~ 85°C
Working temperature:-40°~ 85°C
Industry Standards
Rail Traffic:EN 50121-4
Shock:IEC 60068-2-27
Freefall:IEC 60068-2-32
Vibration:IEC 60068-2-6
Traffic Control:NEMA-TS2
EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8
EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A
Safety

CE/LVD EN60950
CE Mark ,commercial

Mechanical information
Shell:Corrugated metal shell
Safety class:IP30
Dimension:114.8 x 114 x 60mm
Mounting method:Din-rail mounting





Key Featuers



1. Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable.
2. IEEE 802.3af power on RJ45 ports
3. 1 x 10/100/1000Mbps Auto-sensing RJ45 port
4. 1 x 1000Mbps SFP fiber port
5. 4KV Ethernet surge protection, adapt to a harsh outdoor environment
6. Support Auto MDI/MDIX
7. Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
8. IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
9. Max power to15.4W under af standard to each PoE port
10. Detect the PoE models of electrical equipments.
11. A store-and-forward switching mechanism
12. Operating environment temperature:-40 ° ~85 ° c

Warranty & Guarantee



1. All the products we offer are brand new with new components and parts, and we absolutely never use old and refurbished materials.
2. 36 Months Manufacturer Warranty (Excluding contrived damagement or misusage). All the products have been passed the functional test and aging test before delivery.
3. If there is any compatibility problem or any quality problem, the goods can be returned to us to repair or replace. The buyer should be responsible for all the charges of returning and second shipping.
