Use: | FTTH | Cable Type: | Simplex / Duplex |
---|---|---|---|
Jacket Material: | LSZH | Fiber Type: | Single Mode / Multi Mode |
Cable Length: | Can Be Customized | Application: | FTTH FTTB FTTX |
Polishing Manner: | PC,UPC,APC | Insertion Times: | >1000 Times |
OEM Service: | Yes | ||
Highlight: | lc ftth patch cord,om3 ftth patch cord,indoors patchcord ftth |
LE FTTH Patch Cord LC OM3 Fiber Optic Patch Cord
LE Fiber Patch Cable with Future-Proof Speed and a Reliable Connectivity. It provides exceptional transmission performance and low signal losses.Our Standard Ferrules are made of zirconia ceramic, which offers the highest performance and durability of all ferrule material types.Each patch cord is individually and rigorously tested and certified to be within accurate optical insertion loss.LE quality, more than your expect.
Parameter |
Unit |
FC, SC, LC |
ST, MU |
|||||
SM |
MM |
SM |
MM |
|||||
PC |
UPC |
APC |
PC |
PC |
UPC |
PC |
||
Insertion Loss |
dB |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
Return Loss |
dB |
≥40 |
≥50 |
≥60 |
≥30 |
≥40 |
≥50 |
≥30 |
Length |
M |
0.5, 1, 2, 3, 5, 10, 20 (LSZH jacket) |
||||||
Repeatability |
dB |
≤0.3 |
||||||
Insertion Times |
time |
>1000 |
||||||
Operating temperature |
ºC |
-25 ~ +70 |
Our Advantages:
1. 100% MANUFACTURER.
2. Our steel is from Shanghai ShouGang group corporation, higher quality assurance.
3. Japan and Germany CNC machine, professional infrared test equipment, higher precision, more stringent testing.
4. Laser cutting machine and Germany WAGNER auto painting equipment, higher efficiency.
5. 5 ply corrugated with import Meika outside paper carton, glued to avoid scratch, more carefully protection.
6. Professional container loading team, take full advantage of the space and avoid shaking, save your delivery cost.
7. On time delivery rate more than 95%.
