| Place of Origin: | China |
|---|---|
| Brand Name: | LE |
| Certification: | CE/ISO/ROHS |
| Model Number: | LE-GYXTW |
| Minimum Order Quantity: | 2km |
| Price: | 0.903USD/meter |
| Packaging Details: | reel |
| Delivery Time: | 25 working day |
| Payment Terms: | T/T |
| Supply Ability: | 80km per month |
| Product Name: | Armoured Fire Resistant Digital And Composite Fiber Optic Cable | Fiber Count: | 12-84 |
|---|---|---|---|
| Jacket Material: | PE | Application: | FTTH |
| Certification: | ISO9001 | ||
| Highlight: | Armoured Fiber Optic Drop Cable,Fire Resistant Fiber Optic Cable,Digital Composite Multicore Fiber Optic Cable |
||
General Description:
GYXTW fo cable, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel steel wires are placed at the two sides of the steel tape. The cable is completed with a polyethylene (PE) sheath.
Cable Parameters
| Items | Specifications | |
| Fiber Count | 12 | |
Colored Coating Fiber |
Dimension | 250µm±15µm |
| Color | Blue,Orange,Green,Brown, Gray,Natural,Red,Black, Yellow,Purple,Pink,Aqua |
|
Loose Tube |
Dimension | 2.15mm±0.05mm |
| Material | PBT | |
| Color | Natural | |
Strength Member |
Diameter | 0.7mm |
| Material | Steel | |
Outer Jacket |
Dimension | 7.5mm±0.3mm |
| Material | PE | |
| Color | Black | |
Mechanical and Environmental Characteristics
| Items | Unite | Specifications |
| Tension(Long Term) | N | 400 |
| Tension(Short Term) | N | 800 |
| Crush(Long Term) | N/10cm | 300 |
| Crush(Short Term) | N/10cm | 1000 |
| Min. Bend Radius(Dynamic) | mm | 20D |
| Min. Bend Radius(Static) | mm | 10D |
| Installation Temperature | ºC | -20~+60 |
| Operating Temperature | ºC | -40~+70 |
| Storage Temperature | ºC | -40~+70 |
Our Advantages:
1. Laser cutting machine and Germany WAGNER auto painting equipment, higher efficiency.
2. 5 ply corrugated with import Meika outside paper carton, glued to avoid scratch, more carefully protection.
3. Professional container loading team, take full advantage of the space and avoid shaking, save your delivery cost.
4. On time delivery rate more than 95%.
Our Company:
Ningbo Latitude International Trade Co.,Ltd is a professional manufacturer specialized in server cabinet, network cabinet, outdoor cabinet,
wall cabinet and other communication equipment. For over years, we are always devoting ourselves to research, develop,
design and manufacture the indoor and outdoor cabinet products.
Q&A:
1. Q: Are you a factory or trading company?
A: We are a Factory, Distributor and Trading Company.
2. Q: Where is your factory located? How can I visit there?
A: Our factory and office is located in Ningbo City, China. You can fly to Ningbo airport or
Shanghai airport, from home or abroad, are warmly welcome to visit us!
3. Q: Can you do OEM?
A: Yes, we can do OEM products. It's no problem.
4. Q: How can I get some samples?
A: We are honored to offer you samples.
5. Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling for to the every
end. Our factory has gained CE,ROHS,SGS authentication.
