19 Inch 18U SPCC Server Rack Cabinet Network Cabinet With Vented Door

Basic Information
Place of Origin: Zhejiang, China (Mainland)
Brand Name: LE or OEM
Certification: CE,ROHS
Model Number: ND
Minimum Order Quantity: 10 Piece/Pieces
Price: Negotiable
Packaging Details: Assembly packing or flat packing.
Supply Ability: 1000 Piece/Pieces per Week Server Cabinet
Material: SPCC Cold Rolled Steel Cabinet Standard: IEC297-2;CE;ROHS
Degree Of Protection: IP20 Type: 19" Standard Server Cabinet
Color Serial: Ral9004; Ral9005; Ral7035 Loading Capacity: Static Loading: 800kg(on The Adjustable Feet)
High Light:

Network Server Rack Cabinet 19"


18U Server Rack Cabinet


Network Cabinet With Vented Door


19Inch 18U SPCC Server Rack Cabinet With Vented Door



1.Vented front and rear door with excellent ventilation rate above 70%;

2.S-shaped mounting profile, free to move forward and back;
3.Removable side panels with lock optional;
4.Welded steel frame for front and back part, flat packing is available;
5.Adjustable cable entry on the top and bottom cover;
6.Various optional accessories for common using;



 Comply with ANS/EIA RS-310-D, IEC297-2,

 DIN41491, PART1, DIN41491, PART7, ETSI Standard

Material  SPCC quality cold rolled steel;
 Mounting profile: Thickness:2.0mm; Others:1.2mm;
Loading Capacity  Static loading: 800kg (on the adjustable feet)
Degree of protection  IP20
Surface Finish  Degreasing; Pickling; Phosphating; Powder Coated
Product Specification  18U-47U
 Width: 600mm, 800mm
 Depth: 600mm, 800mm, 900mm, 1000mm, 1200mm

19 Inch 18U SPCC Server Rack Cabinet Network Cabinet With Vented Door 0

        19 Inch 18U SPCC Server Rack Cabinet Network Cabinet With Vented Door 1

Main structure (800mm width)
 1. Top cover  2. Fan unit  3. Mounting profile 4. Spacer
 5. Mounting angle  6. Rear door with hexagonal   holes  7. High-density vented rear   door 8. Steel rear door without hole
 9. Bottom panel  10. Heavy duty castor  11. Frame 12. Side panel
 13. Cable management slot  14. Front door  15. Front door 16. Front door
 17. Front door  18. Front door

        19 Inch 18U SPCC Server Rack Cabinet Network Cabinet With Vented Door 2

Main structure (600mm width)
1. Top cover 2. Fan unit 3. Mounting profile 4. Mounting angle
5. Door with hexagonal holes 6. High-density vented door 7. Steel rear door without hole 8. Bottom panel
9. Heavy duty castor 10. Frame 11. Side panel 12. Front door
13. Front door 14. Front door 15. Front door 16. Front door

Factory PIC

Ningbo Latitude International Trade Co., Ltd. is a manufacturer specializing in the

production of server cabinets, network cabinets, outdoor cabinets, wall cabinets and

other communication equipment.

Over the years, we have been committed to the research and development,

design and manufacture of indoor and outdoor cabinet products.


Our Advantages

1. 100% Manufacturer.

2. Our steel is from Shanghai ShouGang group corporation, higher quality assurance.

3. Japan and Germany CNC machine, professional infrared test equipment, higher precision, more stringent testing.

4. Laser cutting machine and Germany WAGNER auto painting equipment, higher efficiency.

5. 5 ply corrugated with import Meika outside paper carton, glued to avoid scratch, more carefully protection.

6. Professional container loading team, take full advantage of the space and avoid shaking, save your delivery cost.

7. On time delivery rate more than 95%.
