Home ProductsServer Rack Cabinet19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels

19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels

19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels
19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels
19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels
Basic Information
Place of Origin: China
Brand Name: LE or OEM
Certification: CE ROHS
Model Number: LE-WD1
Minimum Order Quantity: 10 PCS
Price: USD37.6
Packaging Details: Assembled packing
Delivery Time: 30-45days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000PCS per week
Contact Now
Material: SPCC Quality Cold Rolled Steel Thickness: 1.2mm
Tempered Glass Thickness: 5mm Loading Capacity: 60KGS
Degree Of Protection: IP20 Surface Finish: Degreasing, Pickling, Phosphating, Powder Coated
Product Specification: 4U-27U Width: 600mm
Depth: 550mm, 600mm Color: RAL9004, RAL9005, RAL7035
Highlight:

600x550mm Wall Mounted Enclosure Cabinet

,

6U Wall Mounted Enclosure Cabinet

,

9U Wall Mounted Enclosure Cabinet

19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet with Tempered Glass Front Door and Removable Side Panels



19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 019 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 119 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 2

S/N LE-WD1
Standard

Comply with ANS/EIA RS-310-D, IEC297-2,

DIN41491, PART1, DIN41491, PART7, ETSI Standard
Material SPCC quality cold rolled steel: Thickness:1.2mm;
Tempered glass: Thickness:5.0mm
Loading Capacity Static loading: 60kg
Degree of protection IP20
Surface Finish Degreasing; Pickling; Phosphating; Powder Coated
Product Specification 4U-27U
Width: 600mm
Depth: 550mm, 600mm



4U 6U 9U 12U 15U 18U 22U 27U 600x550 Swing Out Wall Mounted Cabinet Server Rack

4U 6U 9U 12U 15U 18U 22U 27U 600x550 Swing Out Wall Mounted Cabinet Server Rack

Main Structure



1. Cable entry plate

2. Back box (swing)

3. Frame

4. Side panel

5. Mounting profile (L-shaped)

6. Steel front door

7. Tempered glass front door

8. Tempered glass front door with vented border

9. Tempered glass front door with meshed border



19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 5

4U 6U 9U 12U 15U 18U 22U 27U 600x550 Swing Out Wall Mounted Cabinet Server Rack





FAQ

1. Q: Are you a factory or trading company?
A: We are a Factory, Distributor and Trading Company.
2. Q: Where is your factory located? How can I visit there?
A:Our factory and office is located in Ningbo City, China. You can fly to Ningbo airport or Shanghai airport, from home or abroad,
are warmly welcome to visit us!
3. Q: Can you do OEM?
A: Yes, we can do OEM products. It's no problem.
4. Q: How can I get some samples?
A: We are honored to offer you samples.
5. Q: How does your factory do regarding quality control?
A:Quality is priority.We always attach great importance to quality controlling for to the every end. Our factory has gained
CE,ROHS,SGS authentication.

19 Inches Standard 6U 9U 600x550mm 600x600mm Dual Section Hinge Type RAL9004 Black Wall Mounted Enclosure Cabinet With Tempered Glass Front Door And Removable Side Panels 7
