Home ProductsNetwork Patch Panel1U UTP 24 Port Cat5E Cat6 UTP Patch Panel

1U UTP 24 Port Cat5E Cat6 UTP Patch Panel

1U UTP 24 Port Cat5E Cat6 UTP Patch Panel
1U UTP 24 Port Cat5E Cat6 UTP Patch Panel 1U UTP 24 Port Cat5E Cat6 UTP Patch Panel 1U UTP 24 Port Cat5E Cat6 UTP Patch Panel 1U UTP 24 Port Cat5E Cat6 UTP Patch Panel 1U UTP 24 Port Cat5E Cat6 UTP Patch Panel
Basic Information
Place of Origin: Ningbo, China
Brand Name: LE
Certification: CE/ISO/ROHS/TUV
Model Number: LE-P2548
Minimum Order Quantity: 100pcs
Price: US$5-US$10
Packaging Details: Assembled packing
Delivery Time: 20-30days
Payment Terms: L/C,T/T,Western Union,MoneyGram,D/P
Supply Ability: 5000pcs per day
Contact Now
Type: UTP Port: 48
Material: CRS Insertion Time: 1000 Matching Cycles
Height: 2U Application: Telecommunication
Certificates: CE/ISO/ROHS/TUV Color: Black
Highlight:

1U 24 port UTP patch panel

,

Cat6 UTP network patch panel

,

rack mount UTP patch panel



19inch 2U UTP 12Port CAT5e Adn CAT6 Patch Panel With Cable Management Option




General Description:


1. 19inch 2U UTP 12Port CAT5e Adn CAT6 Patch Panel With Cable Management Option,
2. Operation temperature:-40°C to 60°C, Relative humidity:85%(30°C), Air pressure:70-106Kpa
3. Complete metalation and reed construction
4. Suitable for 22AWG/23AWG/24AWG/26AWG solid wires
5. Color: black, RAL 9005
6. Printing:white
7. Labelling fields:1-24

1U UTP 24 Port Cat5E Cat6 UTP Patch Panel 0

Features:



1. Front Panel: 1.5mm thickmness metal panel(SPCC), painting on surface
2. Metallic Frame: 1.5mm thickness
3. Housing material: ABS or PC, UL94-V0 or UL94-V2
4. Meet or exceed the current T568A and T568B standard
5. Termination: Dual IDC, 110 IDC, Krone IDC
6. Panel frame: black or Ivory electrostatic powder-coated steel
7. IDC contact material: phosphor brone with tin plating over nickel
8. contact material: phosphor brone with gold plating over nickel
9. Punching duration:≥250 times
10. Inserting duration:≥750 times
11. Dielectric withstand voltage: 1000V AC RMS, 60Hz 1min
12. Insulation Resistance: 500M-ohm
13.High reliability and superior performance


1U UTP 24 Port Cat5E Cat6 UTP Patch Panel 1
1. Q: Are you a factory or trading company?
    A: We are a Factory, Distributor and Trading Company.
2. Q: Where is your factory located? How can I visit there?
    A: Our factory and office is located in Ningbo City, China. You can fly to Ningbo airport or
    Shanghai airport, from home or abroad, are warmly welcome to visit us!
3. Q: Can you do OEM?
    A: Yes, we can do OEM products. It's no problem.
4. Q: How can I get some samples?
    A: We are honored to offer you samples.
5. Q: How does your factory do regarding quality control?
    A: Quality is priority. We always attach great importance to quality controlling for to the every
    end. Our factory has gained CE,ROHS,SGS authentication.

Tag:

high density patch panel

ethernet cable patch panel

feed through patch panel
